HIKVISION DS-KIT342MX

Name: HIKVISION DS-KIT342MX
Brand: S.B. TELELINK PVT. LTD.
Price: 16520 INR
Availability: InStock

Price 16520 INR/ Piece

Get a Price/Quote

MOQ : 5 Pieces

HIKVISION DS-KIT342MX Specification

Frequency Band
50/60 Hz

Connectivity Type
Wired

License Free
Yes

Interface
RS485, Alarm In/Out, Ethernet

Operating Mode
Indoor (Monitor) & Outdoor (Camera)

Size
Outdoor Station: 174mm x 96mm x 31mm, Indoor Station: 200mm 140mm 15mm

Mounting Type
Surface Mount

Standard
PAL/NTSC

Technology
Analog HD Video Door Phone

Special Features
Intercom, Remote Unlock, Real-time Video Monitoring

Remote Control
Mobile App Supported

Application
Residential and Commercial Security

Camera Size
Pin-hole Camera, 1/3 Progressive Scan CMOS

Screen Resolution
7-inch Color TFT LCD, 1024600

Power Supply
12V DC

Output Formats
CVBS

Camera Resolution
720p

Installation
Support Wall-mount

Communication
4-wire connection

Storage
MicroSD Card up to 32GB

Ingress Protection
IP65 (Outdoor Unit)

Viewing Angle
Approx. 90°

Operating Voltage
12 VDC ± 25%

Audio
Two-way Audio, Noise Suppression

Ringtone
Selectable Tones

Door Unlock
Remote and Local Unlock Supported

Night Vision
IR LED for low-light conditions

Temperature Range
-10°C to +55°C

Power Consumption
<10W (indoor station), <5W (outdoor station)

Firmware Upgrade
Network Upgrade Supported

Expansion
Supports up to 3 indoor stations per outdoor station

Material
Aluminum Alloy (Outdoor), ABS (Indoor)

HIKVISION DS-KIT342MX Trade Information

Minimum Order Quantity
5 Pieces

FOB Port
JAIPUR

Payment Terms
Cash Advance (CA), Cheque, Telegraphic Transfer (T/T)

Delivery Time
1 Days

Sample Available
Yes

Sample Policy
Contact us for information regarding our sample policy

Packaging Details
STANDARD

Main Domestic Market
All India

About HIKVISION DS-KIT342MX

Max.1500 faces capacity, and Max.3000 cards
Face Recognition Terminal, 4.3-nch LCD touch screen,2 Mega pixel wideangle lens,Builtin Mifare card reading
module
Two-way audio with client software, indoor station, and main station; Supports TCPIP
Supports ISAPI, ISUP5.0
Configuration via the web client
Face Recognition Distance 0.3 m to 1.5 m
Duration 0.2 sUser
Accuracy rate 99
Supports mask recogniti

High-Definition Security Monitoring

Benefit from the 720p camera with 90 viewing angle and IR night vision, ensuring clear and wide surveillance around your property, even during low-light situations. Real-time video streaming and pin-hole CMOS technology offer dependable visual monitoring throughout all hours.

Seamless Communication & Control

With two-way audio, noise suppression, and intercom capabilities, the system allows effortless conversations between residents and visitors. Unlock your door remotely or locally, customize ringtones, and control operations conveniently via a user-friendly mobile application.

Flexible Installation & Reliable Durability

Designed for both indoor and outdoor environments, the DS-KIT342MX supports wall-mount installation and withstands harsh weather conditions, thanks to its IP65 rating and sturdy aluminum alloy construction of the outdoor unit. The indoor and outdoor stations are stylish and compact, fitting various architectural needs.

FAQ's of HIKVISION DS-KIT342MX:

Q: How do I install the HIKVISION DS-KIT342MX in my premises?

A: Installation is simple with the included support for wall-mounting and a 4-wire connection setup. The outdoor station is designed for surface mounting and provides IP65 ingress protection, making it suitable for external placement in residential or commercial settings.

Q: What is the maximum number of indoor stations I can connect to one outdoor station?

A: The DS-KIT342MX system supports up to three indoor stations per outdoor unit, offering flexibility for multi-room monitoring and communication within larger properties.

Q: When should I consider upgrading the firmware on my devices?

A: Firmware upgrades are recommended when new features or security updates are available. The DS-KIT342MX supports network-based firmware upgrades, ensuring your system remains current and secure with minimal effort.

Q: Where can I use the DS-KIT342MX analog HD door phone system?

A: This video door phone is suited for both residential and commercial premises, providing reliable entry monitoring and communication in houses, apartments, offices, or gated communities.

Q: What storage options are available for video footage?

A: You can insert a microSD card of up to 32GB into the system to record and store footage. This allows easy playback and review of important events directly from the device or app.

Q: How does the remote unlock feature work and what is its benefit?

A: Remote unlock enables users to grant access via a mobile application or indoor station, improving flexibility and safety by allowing control over door access without direct line-of-sight or physical proximity.
